Gigabit POE Switch 4 port

5 Port Full Gigabit PoE Switch with 2* 2.5Giga Uplink

Introduction :

4*10/100/1000M RJ45 POE port+1*10/100/1000M RJ45 ports + 2* 2.5G SFP ports Unmanaged PoE Switch;Standard power is 15.4W/port,Maximum power: 30W/port.
2. With the Dial code switch:
E: Turn on, 1-4 Port Support to 300meter distance;
V: Turn on, 1-4 Port support each port VLAN;
D: Turn on, 1-4 Port support AI-PoE Network self-healing mode(PoE Watchdog function), Automatic solve the camera problem &reduce after-sale.
3. PoE default: 1, 2(+)/3, 6(-).
4. 65W build-in power adapter.

Fixed Port	410/100/1000Base-T/TX PoE ports (Data/Power) 110/100/1000Base-T/TX Uplink RJ45 ports (Data) 2* 1G/2.5G Uplink SFP ports (Data)
POE Port	Port 1-4 support PoE @ IEEE802.3af/at
Features	With the EVD Dial code switch: E: AI Extend 300meters transmission; V: Turn on, 1-4 Port support each port Isolation & VLAN; D: Turn on, 1-4 Port support AI-PoE Network self-healing mode (PoE Watchdog function), Automatically solve the camera problem & reduce after-sale.
Network Protocol	IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; IEEE802.3u 100Base-TX; IEEE802.3ab 1000Base-T; IEEE802.3x.
Ethernet Port Feature	10/100/1000Base–T(X) automatic detection, full/half Duplex MDI/MDI-X adaptive
Switching Capacity	20Gbps
Forwarding Mode	Store and Forward
MAC	4K
Buffer Memory	2M
Twisted Pair Transmission	10BASE-T:Cat5 UTP(≤300 meter) 100BASE-TX:Cat5 or later UTP(≤100 meter) 1000BASE-T: Cat5e or later UTP (≤100 meter)
Power Supply Pin	Default 1/2(+), 3/6(-)
MAX / AVERAGE Power Per Port	30W/15.4W
Total PWR / Input Voltage	65W
Power Consumption	Standby:<4W;Full load:<65W
LED Indicator	Power indicator: PWR (Green); Network indicator: 1-4(Link/Act)/ (Green), 5-6(Link/Act)/ (Green),
Power Supply	Built-in power adaptor AC100~240V 50-60Hz, 65W
Operation TEMP / Humidity	-20~+55°C:5%~90% RH non condensing
Storage TEMP / Humidity	-40~+75°C;5%~95% RH non condensing
Dimension	19513040mm
Net /Gross Weight	<0.8kg / <1kg
Installation Method	desktop type, wall mounted;
Protection	IEC61000-4-2(ESD): ±8kV contact discharge, ±15kV air discharge IEC61000-4-5(Lightning protection/Surge): Power:CM±4kV/DM±2kV; Port: ±4kV
Protection Level	IP30
Certification	CCC;CE mark, commercial;CE/LVD EN60950; FCC Part 15 Class B;RoHS
Warranty	1 years, lifetime maintenance.
