2.5G POE Switch 24 port

The 2.5G series of unmanaged multi-Gigabit network switches is designed to provide high-speed connectivity up to 2.5Gbps for small and medium-sized networks, including home offices, school dormitories, offices, and small-scale surveillance systems. Featuring a large-capacity cache chip and full-port support for wire-speed forwarding, it ensures stable, uninterrupted video and data transmission 24/7, making it an ideal solution for environments that demand reliable performance.

Fixed Port	24100/1000/2500M RJ45 POE ports 610G SFP ports
PoE Ports	1-2 port supports IEEE802.3af/at/bt, max 90W/port PoE out 3-24 port supports IEEE802.3af/at, max 30W/port, PoE out
Network protocol	IEEE802.3 (Ethernet) IEEE802.3u (Fast Ethernet) IEEE802.3ab(Gigabit Ethernet) IEEE 802.3bz（5G Ethernet） IEEE 802.3z（Gigabit Ethernet） IEEE 802.3ae（10G Ethernet） IEEE802.3x (Flow control)
RAM	512MBytes
Jumbo frame	12K byte
Bandwidth	240Gbps
MEMORY	4G DDR3
FLASH	512MBytes
Buffer	16 Mbit SRAM Packet Buffer
Packet Forwarding	178.56Mpps
MAC Address	32K
Transmission Distance	10BASE-T: Cat3,4,5UTP(<250 meter) 100BASE-TX: Cat5 or later UTP(150 meter) 1000BASE-TX: Cat6 or later UTP(150 meter) 2500BASE-TX : Cat6 or later UTP(100 meter) SFP: Supports 100M/1G/2.5G/10G all types
LED Indicator	PWR: Master slave power indicator lights /SYS LED 1-24 Ports: Link/Act LED 25-30 Ports: Link/Act LED、10G speed LED 1-24POE: POE on LED (for POE item)
Power Supply	Built-in power supply AC: 100-240Vac 50/60Hz 0.6A max45W AC: 100-240Vac 50/60Hz 5A max435W (for POE item)
Lightning protection level	6KV8/20us; IP30
Working Environment	Operating Temperature: -20~70℃ Storage Temperature: -40~70℃ Storage Humidity: 5% to 90% non-condensing
Dimension	44029045mm
