The QSFP+ module is designed for use in 40GBASE Ethernet throughput up to 2km over single mode fiber (SMF) using a wavelength of 1310nm via a MTP/MPO-12 connector. This transceiver is compliant with 100G PSM4 MSA. Digital diagnostics functions are also available via the I2C interface, as specified by the 100G PSM4 MSA, to allow access to real-time operating parameters. With these features, this easy to install, hot swappable transceiver is suitable to be used in various applications, such as data centers, high-performance computing networks, enterprise core and distribution layer applications
QSFP-40G-PLRL4 40GBASE-PLR4L QSFP+ Optical Transceiver Module (SMF, 1310nm, 2km, MTP/MPO, DOM)
| SFP Module | 40G QSFP+PLR4L SMF 1310nm 2km MTP/MPO |
|---|---|
| Form Factor | QSFP+ |
| Max Data Rate | 41.25Gbps |
| Wavelength | 1310nm |
| Max Cable Distance | 2km |
| Connector | MTP/MPO-12 Male |
| Optical Components | DFB CWDM |
| Media | SMF |
| DOM Support | Yes |
| TX Power | -9.4~0.5dBm |
| Receiver Sensitivity | <-14.4dBm |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Protocols | IEEE 802.3 40GBASE-SR4, SFF-8436 |
